Different Types of Cable Insulators

Electrical Cable can come with insulation or not. There are some type of over head transmission and distribution cable don’t have insulation on it because it stay up from ground level. But if a cable is passing through ground level and human and animal is crossing nearby then there is a big possibility that anyone can get Electrical Shock if the cable is not having insulation. Like cable insulation a cable insulator is also important equipments in power transmission and distributions Read More …

Aluminium Conductor Steel Rein-Forced (ACSR)

In my last post I talked about the various types of electrical cable conductor. Now I will discuss about (ACSR) Aluminium Conductor Steel Rein-Forced. So, let’s go. Aluminium Conductor Steel Rein-Forced: (ACSR) or Aluminium Conductor Steel Rein-Forced consist of a core of galvanized steel strand and it surrounded by a numbers of Aluminium strands. Normally the steel conductors are used for galvanized in order to prevent any kind of rusting and electrolytic corrosion. The cross section of the two metals Read More …

Various Types of Electrical Cable Conductor

Without Conductor its not an Electrical Cable. In market you will find different types of electrical cable with few types of conductor. In this post we will learn Various Types of Electrical Cable Conductor. What is Electrical Conductor: The material, which resist a few portion of current flow known as conducting material. But when, it used in bare strand or solid material then its called conductor. Mainly conducting material used for transmission or the distribution of electric power. For this reason Read More …

Electrical Cable Classification and Specification

In my last post I talked about, what is cable insulation and various type of insulation? Today I will discuss about the cable classification and specification of electrical cable. So let’s go. First of all I want to tell you why you need to know about the electrical cable classification and specification? OK, let’s consider you are an electrical engineer or a technician and its means you are on work. When you are handling that kind of responsibility then you Read More …

What is Cable Insulation and Type of Insulation?

My last post was about what are electrical cable and its type? Today I will discuss about cable insulation type. So let’s go. First of all Cable Insulation: The three most common available materials are used as insulation for any kind of power cable Tape insulation such as impregnated paper or varnish paper, Rubber or rubber like Synthetic compound such as Silicone rubber, butyl rubber and oil based rubber. Thermo-plastics such as Polyvinyl chloride (PVC) and Cross linked poly ethylene’s (XLPE). Read More …

What are Electrical Cables and its Types?

Electrical Cable is a common element in electrical work. In this post we will learn What are Electrical Cables and its Types? What is Electrical Cable? The conductor which is normally insulated by insulating material is known as cable. Generally cable is used for transmission and distribution of electric power by under the ground system. Underground cables are used to transmission and distribution of electric power, where it becomes impracticable to make use of overhead construction. Such location is may be Read More …
